China Laser Rangefinder Module Manufacturers, Suppliers, Factory
High performance OEM laser ranging sensor solution empowering for your innovation.
Jioptics With expertise and cutting-edge proprietary technology, you can provide 1-300km reliable laser ranging solution, laser band covering 905nm, 1064nm, 1535nm, 1.54um, 1570nm laser, to meet your different needs.
For specific needs, we provide ODM customized services to help solve any technical problems and help your innovation.
- View as
2mrad 2km Laser Rangefinder module for Anti drone ststem
The compact STA-WR2000X Laser rangefinder module is highly suitable for integration into the air defense systems of the army and navy. The distance measurement module adopts the most advanced diode pumped erbium glass laser, which has high availability and low maintenance cost. Its 2mrad divergence angle can measure UAVs with a cross-section of 0.1 ㎡ up to 2000 meters, making it an important component of anti drone systems.
Read MoreSend Inquiry
2mrad 1km Laser Rangefinder module for Anti drone ststem
The compact STA-WR1000X Laser rangefinder module is highly suitable for integration into the air defense systems of the army and navy. The distance measurement module adopts the most advanced diode pumped erbium glass laser, which has high availability and low maintenance cost. Its 2mrad divergence angle can measure UAVs with a cross-section of 0.1 ㎡ up to 1000 meters, making it an important component of anti drone systems.
Read MoreSend Inquiry
2000m Micro Laser Rangefinder Module(LRF)
The STA-W2X miniature laser ranging module uses a 905nm semiconductor laser, which has the characteristics of long range, low power consumption, small size, and eye safety. It is very suitable for integrating small unmanned aerial vehicle pods, handheld night vision devices, thermal imaging and other equipment.
Max range: 2000m
Ranging accuracy: ± 1m
Ranging frequency: 1-3Hz
Weight:10g ±0.5g
1200m Micro Laser Rangefinder Module(LRF)
The STA-D09A miniature laser ranging module uses a 905nm semiconductor laser, which has the characteristics of long range, low power consumption, small size, and eye safety. It is very suitable for integrating small unmanned aerial vehicle pods, handheld night vision devices, thermal imaging and other equipment.
Max range: 1200m
Ranging accuracy: ± 1m
Ranging frequency: Single-shot ranging,1Hz,2Hz
Weight:10g ±0.5g
200Hz 350m Mini Laser Rangefinder Module(Lidar)
STA-M350X Miniature Laser Ranging Module adopts human eye-safe 905nm semiconductor laser component, which has the advantages of long range, low power consumption, small size, light weight, long service life, etc., and it is very suitable for the integration of UAV pods, night vision, thermal imaging and other equipments.
Measurement range:1-350m
Measuring natural targets≥150m
Ranging frequency:200Hz
Measurement accuracy: ±0.1m
Weight ≤14 ±0.5g
2000m Mini Laser Rangefinder Module(LRF)
STA-M020X Miniature Laser Ranging Module adopts human eye-safe 905nm semiconductor laser component, which has the advantages of long range, low power consumption, small size, light weight, long service life, etc., and it is very suitable for the integration of UAV pods, night vision, thermal imaging and other equipments.
Measurement range: 5-2000meters
Measurement of trees ≥1500 meters
Measurement accuracy ±1m
Weight ≤14 ±0.5g
As a professional China Laser Rangefinder Module manufacturers and suppliers called Jioptics. High quality Laser Rangefinder Module are very popular in all countries. We can provide low price products, If you want products made in China, you can get it from our factory. Welcome to buy products from our factory.
