1535nm 16km Laser Rangefinder Module
The JIOPTICS 1535nm STA0816 laser rangefinder module is specially designed for OEM integration and can provide accurate measurement for fire control systems, aircraft/UAV, tank/UGA, ships, border surveillance systems and other applications.
Maximum range ≥ 16000m
Range 2.3×2.3m target size ≥8000m
Distance measuring accuracy ± 1m
Measuring accuracy ≥ 98%
Weight ≤ 89.5g
1535nm 10km laser rangefinder module
The JIOPTICS 1535nm STA0410 laser rangefinder module is specially designed for OEM integration and can provide accurate measurement for fire control systems, aircraft/UAV, tank/UGA, ships, border surveillance systems and other applications.
Maximum range ≥ 10000m
Range 2.3×2.3m target size ≥4000m
Distance measuring accuracy ± 1m
Measuring accuracy ≥ 98%
Weight ≤ 69.5g
1064nm YAG Laser 15mJ 20Hz
The 1064nm YAG laser is one of the most widely used of all solid-state lasers, and can be used in materials processing, holographic technology, ranging, target illumination and indication, surgery and other fields.
Peak wavelength: 1064nm
Mono-pulse energy: 15mJ
Operating frequency: 20Hz
Operating temperature: -40℃~+55℃
1064nm YAG Laser 15mJ 5Hz
The 1064nm YAG laser is one of the most widely used of all solid-state lasers, and can be used in materials processing, holographic technology, ranging, target illumination and indication, surgery and other fields.
Peak wavelength: 1064nm
Mono-pulse energy: 15mJ
Operating frequency: 20Hz
Operating temperature: -40℃~+55℃
1570nm OPO Laser 80mJ 20Hz
High-power electro-optical Q-switched 1570nm OPO laser,with built-in drive circuit control system,pulse repetition rate of 1~20hz(adjustable),peak power≥80mJ,divergence angle≤6mrad,is an ideal light source for laser radar,laser ranging and photoelectric countermeasures.
Peak wavelength: 1570nm
Mono-pulse energy: 80mJ
Operating frequency: 1-20Hz（adjustable）
Operating temperature: -40°C~+60°C
1570nm OPO Laser 10mJ 20Hz
The human eye safety miniature 1570nm OPO laser has the characteristics of small size, compact structure, low threshold, high conversion and repetition rate, large pulse capacity and simple structure, which is very suitable for laser LIDAR, laser ranging and target recognition.
Peak wavelength: 1570nm
Mono-pulse energy: 10mJ
Operating frequency: 20Hz
Operating temperature: -40℃~+55℃
